气动与plc节制综合尝试台,单片机节制功效尝试装配

一、根本简介
气动尝试台是根据《液压与气压传动》、《气动节制手艺》等通用讲授图纸文档尝试指点书及尝试指点书内容请求，参考泛博师生的倡议，经心设想而成。该体系除能够实施惯例的气动根本节制线路尝试外，还可实施仿照气动节制手艺利用尝试、气动手艺课程设想，和可编法式节制器 （plc）进修掌控掌握掌控掌握掌控掌握及其根本利用尝试等，是机电完善调集的经典范范型尝试装备。
气动尝试装备顺应于大中专院校、技校、职业黉舍中的机器工程、机电一体化、主动化专业开设《液压与气压传动》、《气动节制手艺》、《 PLC可编法式节制器道理及利用》等相干课程的讲授尝试，同时也可作为机、电、气一体化的综合尝试台。先生颠末现实实操尝试及课程设想，能够精确、抽象、深切地懂得、掌控掌握气动元件的机关、气动线路的节制道理及设想方式等。和掌控掌握PLC可编法式节制器的功效，节制道理及编程技能等。
二、首要手艺功效数值
1、写入电源：220V±l0%，50Hz；
2、装配容量（KV）（KV）（KV）：≤1kVA；
3、功课情况温度（℃）（℃）（℃）：－5℃～40℃；
4、功课湿度：≤90%(40℃时)；
5、表面尺寸：1500mm×650mm×1750mm
6、静音氛围紧缩机：功课电源：AC220V；机电功率（W）（W）（W）：250W公称容量（KV）（KV）（KV）10L；规格限制输入气压1Mpa
7、PLC主机模子块：主机选用三菱FX2N-32MR，18路开关量写入，14路继电输入。
8、装备装备装备有节制模子块：电源模子块，PLC节制模子块，继电器节制模子块，节制按钮模子块，气动元件零丁模子块等。
9、尝试装配外型尺寸：1500mm×650mm×1750mm
